SI-KRM0808 Octuplet Silencer/2k/kn

Description

SI-0808 and SI-2408 are Octuplets used together as a powerful clean routing switch solution for mission-critical applications.It permits clean routing switch of SD-SDI, HD-SDI and 3G-SDI signals.

Product Highlight

*Support 3G/HD/SD-SDI 8 inputs and 8 outputs
* Internal generatedthe clock to ensure the input 3G-SDI video signal without any change
* Internal VDM (Video Display Metafile)
* Redundant power supply
* Ethernet remote control by “Konvision Device Manager” and third party control software
* Operating temperature alarm switch

Specifications
Video Inputs
Signal 8 x 3G/HD/SD-SDI
Connectors BNC
Impedance 75
Video Outputs
Signal 8 x 3G/HD/SD-SDI
Connectors BNC
Impedance 75
Control Interface
Signal Ethernet/RS422
Connectors 2 x Rj45
Control software XP/Win7/Win8
Power supply
Supply AC100-240V 50/60Hz
Power consumption 30W
Redundant PSU Yes
General
Dimension 437*347*44cm
Operating Temp -10°~ 50°
Installation 1RU standard 19″ rackmount
¤specifications may be changed without prior notice.
